Description
[rt_button_style title=”CATALOG” link=”url:https://www.saxco.com.my/wp-content/uploads/2017/08/product_0_1_0_247.pdf|||”]
| Camera | ||
|---|---|---|
| Image Sensor | 1/2.8″ 2.4 Megapixel CMOS | |
| Effective Pixels | 1984(H)x1225(V) | |
| Electronic Shutter | 1/3s~1/100,000s | |
| Video Frame Rate | 25/30/50/60fps@720P; 25/30fps@1080P | |
| Synchronization | Internal | |
| Min.Illumination | 0.05Lux/F1.8, 0Lux IR on | |
| Video Output | 1-channel BNC HDCVI high definition video output/ CVBS standard definition video output (Can switch) |
|
| Camera Features | ||
| Max.IR LEDs Length | 30m, Smart IR | |
| Day/Night | Auto(ICR)/Color/B/W | |
| Noise Reduction | 2D/3D | |
| OSD Menu | Support | |
| Lens | ||
| Focal Length | 3.6mm (6mm, 8mm optional) | |
| Angle of View | H: 88º(55º/38.6º) | |
| Mount Type | M12 | |
| General | ||
| Power Supply | DC12V±20% | |
| Power Consumption | Max 3.5W | |
| Working Environment | -30°C~ 60°C / Less than 95%RH (no condensation) | |
| Transmission Distance | Over 500m via 75-3 coaxial cable | |
| Ingress Protection | IP67 | |
| Dimensions | Φ108mm×85.4mm | |
| Weight | 0.35KG | |
| Material | Metal (inner core) Plastic (Outside) | |
