| Camera | ||
|---|---|---|
| Image Sensor | 1/2.7″ 2Megapixel CMOS | |
| Effective Pexel | 1936(H)× 1097(V) | |
| Electronic Shutter | 1/25~1/100000s | |
| Video Frame Rate | 25/50fps@720P; 25fps@1080P | |
| Synchronization | Internal | |
| Min. Illumination | 0.02Lux/F2.0, 0Lux IR on | |
| Video Output | 1-channel BNC high definition video output/ CVBS standard definition video output(Can switch) |
|
| Camera Features | ||
| Max. IR LEDs Length | 20m, Smart IR | |
| Day/Night | Auto(ICR) / Color / B/W | |
| Backlight Compensation | DWDR | |
| Noise Reduction | 2D | |
| OSD Menu | Support | |
| Lens | ||
| Focal Length | 3.6mm (6mm optional) | |
| Angle of View | H: 89.9º(59.4º) | |
| Mount Type | M12 | |
| General | ||
| Power Supply | DC12V±25% | |
| Power Consumption | Max 2.8W | |
| Working Environment | -30°C~ 60°C / Less than 95%RH (no condensation) | |
| Transmission Distance | Over 500m via 75-3 coaxial cable | |
| Ingress Protection | IP67 | |
| Dimensions(W×D×H) | Φ70mm×154mm | |
| Weight | 0.3kg | |
| Material | Metal | |
