| Camera | ||
|---|---|---|
| Image Sensor | 1/2.7″ 2 Megapixel CMOS | |
| Effective Pixels | 1920(H)x1080(V) | |
| Electronic Shutter | 1/25~1/100000s | |
| Video Frame Rate | 25/50fps@720P; 25fps@1080P | |
| Synchronization | Internal | |
| Mini.Illumination | 0.02Lux/F2.0, 0Lux IR on | |
| Video Output | 1-channel BNC high definition video output/CVBS standard video output |
|
| Camera Feature | ||
| Max.IR LEDs Length | 20m, Smart IR | |
| Backlight Compensation | DWDR | |
| Day/Night | Auto(ICR)/Color/B/W | |
| Noise Reduction | 2D | |
| OSD Menu | Support | |
| Lens | ||
| Focal Length | 3.6mm (6mm optional) | |
| Angle of View | H: 89.9º(59.4º) | |
| Mount Type | M12 | |
| General | ||
| Power Supply | DC12V± 25% | |
| Power Consumption | Max 2.8W | |
| Working Environment | -40°C~ 60°C / Less than 95%RH (no condensation) | |
| Transmission Distance | Over 500m via 75-3 coaxial cable/Less than 95%%RH (no condensation) |
|
| Ingress Protection | IP67 | |
| Dimensions (W x D x H) | 70mm x 154mm | |
| Weight | 0.2KG | |
| Material | Plastic | |
