SpecificationsDownload
| System | ||
|---|---|---|
| Main Processor | Embedded Processor | |
| Operating System | Embedded LINUX | |
| Display | ||
| Interface | 1 HDMI, 1 VGA | |
| Resolution | 1920×1080, 1280×1024, 1280×720, 1024×768 | |
| Multi-screen Display | 4CH: 1/4/6 | |
| OSD | Camera tittle, Time, Video loss, Camera lock, Motion detection, Recording |
|
| Video Detection and Alarm | ||
| Trigger Events | Recording, PTZ, Tour, Alarm Out, Video Push, Email, FTP, Snapshot, Buzzer and Screen Tips |
|
| Video Detection | Motion Detection, MD Zones: 396 (22×18), Video Loss, Tampering and Diagnosis |
|
| Alarm Input | 8/8/16 | |
| Relay Output | 3 | |
| Playback and Backup | ||
| Playback | 4CH: 1/4 | |
| Search Mode | Time/ Date, Alarm, MD and Exact Search (accurate to second), Smart search |
|
| Playback Function | Play, Pause, Stop, Rewind, Fast play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Full Screen, Repeat, Shuffle, Backup Selection, Digital Zoom |
|
| Backup Mode | USB Device/Network | |
| Storage | ||
| Internal HDD | 2 SATA Port, up to 8TB capacity for each disk | |
| eSATA | N/A | |
| Auxiliary Interface | ||
| USB | 4CH:2 USB Ports (2 USB 2.0 ) | |
| RS232 | N/A | |
| RS485 | 1 Port, for PTZ Control | |
| Audio and Video | ||
| HDCVI Camera Input | 4 Channel | |
| IP Camera Input | 4 2/8 4/16 8 Channel, each channel up to 5MP | |
| Audio In/Out | 4 Channel input,1 Channel output, RCA | |
| Two-way Talk | Reuse audio in(channel 1)/out, RCA | |
| Recording | ||
| Compression | H.264 /H.264 | |
| Resolution | 1080P, 720P, 960H, D1, HD1, BCIF, CIF, QCIF | |
| Record Rate | Main stream: 1080P/720P/960H/D1/HD1/BCIF/CIF/ QCIF (1~25/30fps) Sub steram: D1/CIF/QCIF(1~25/30fps |
|
| Bit Rate | 1 Kbps~6144Kbps Per Channel | |
| Record Mode | Manual, Schedule (Regular, Continuous), MD(Video detection: Motion Detection, Video Loss, Tampering), Alarm, Stop |
|
| Record Interval | 1~60 min(default: 60min), Pre-record: 1~30 sec, Post-record: 10~300 sec |
|
| Network | ||
| Interface | 4CH: 1 RJ-45 Port (100M) | |
| Network Function | HTTP, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE,DDNS, FTP, Alarm Server, P2P,IP Search (Support Dahua IP camera, DVR, NVS, etc.) |
|
| Max.User Access | 128 users | |
| Smart Phone | iPhone, iPad, Android | |
| Interoperability | ONVIF 2.42, CGI Conformant | |
| Electrical | ||
| Power Supply | 4/8CH: DC12V/4A | |
| Power Consumption | <15W (Without HDD) | |
| Environmental | ||
| Operating Conditions | -10°C ~ 55°C ( 14°F ~ 131°F), 0~ 90% RH | |
| Storage Conditions | -20°C ~ 70°C (-4°F ~ 158°F), 0~ 90% RH | |
| Construction | ||
| Dimensions | 1U. 375mm x 287mm x 53mm (14.8″x 11.3″x2.1″) |
|
| Net Weight | 2.35KG(5.2Ib)(without HDD) | |
| Gross Weight | 3.2KG(7.05Ib) | |
| Installation | Desktop installation | |
| Certifications | ||
| Certifications | FCC: Part 15, Subpart B ICES 003 Issue 6 CE: EN 55032: 2012 AC 2013 (Class B) EN 55024 : 2010 EN 61000-3-2 : 2014 EN 50130-4: 2011 EN 61000-3-3 : 2013 UL 60950-1 and CAN/CSA C22.2 No. 60950-1-07 |
|
