Description
| Camera | ||
|---|---|---|
| Image Sensor | 1/2.7” 5Megapixel progresive CMOS | |
| Effective Pixels | 2592(H)x1944(V) | |
| RAM/ROM | 512MB/32MB | |
| Scanning System | Progressive | |
| Electronic Shutter Speed | Auto/Manual, 1/3 ~ 1/100000s | |
| Minimum Illumination | 0.03Lux/F2.0( Color,1/3s,30IRE) 0.3Lux/2.0( Color,1/30s,30IRE) 0Lux/F2.0(IR on) |
|
| S/N Ratio | More than 50dB | |
| IR Distance | Distance up to 30m (98ft) | |
| IR On/Off Control | Auto/Manual | |
| IR LEDs | 18 | |
| Lens | ||
| Lens Type | Fixed | |
| Mount Type | Board-in | |
| Focal Length | 2.8mm (3.6mm optional) | |
| Max.Aperture | F2.0/F2.0 | |
| Angle of View | H:96°/78°, V:70°/58° | |
| Focus of View | Fixed | |
| Close Focus Distance | N/A | |
| DORI Distance | 2.8 mm | Detect : 63m(207ft) Observe : 25m(82ft) Recognize : 13m(43ft) Identify : 6m(20ft) |
| 3.6 mm | Detect : 80m(262ft) Observe : 32m(105ft) Recognize : 16m(52ft) Identify : 8m(26ft) |
|
| PTZ | ||
| Pan/Tilt Range | Pan:0° ~360° ;Tilt:0° ~90° ;Rotation:0° ~360° | |
| Intelligence | ||
| Event Trigger | Motion detection, Video tampering, Scene changing, Network disconnection, Ip address conflict, Illegal access, Storage anomaly |
|
| IVS | Tripwire, Intrusion | |
| Video | ||
| Compression | H.265/H.264H/MJPEG(Sub Stream) | |
| Smart Codec | Support H.265 /H.264 | |
| Streaming Capability | 2 Streams | |
| Resolution | 5M(2592×1944)/4M(2688×1520)/3M(2304×1296/2048×1536)/ 1080P(1920×1080)/720P(1280×720)/ D1(704×576/704×480)/VGA(640×480)/ CIF(352×288/352×240) |
|
| Frame Rate | Main Stream | 5M(1 ~ 15fps)/3M (1 ~ 25/30fps) |
| Sub Stream | D1(1 ~ 25/30fps) | |
| Bit Rate Control | CBR/VBR | |
| Bit Rate | H.265: 12K ~ 8448Kbps H.264: 32K ~ 10240Kbps |
|
| Day/Night | Auto(ICR) / Color / B/W | |
| BLC Mode | BLC / HLC / WDR(120dB) | |
| White Balance | Auto/Natural/Street Lamp/Outdoor/Manual | |
| Gain Control | Auto/Manual | |
| Noise Reduction | 3D DNR | |
| Motion Detetion | Off/On (4 Zone, Rectangle) | |
| Region Interest | Off/On (4 Zone) | |
| Electronic Image Stabilization(EIS) | N/A | |
| Smart IR | Support | |
| Digital Zoom | 16x | |
| Flip | 0°/90°/180°/270° | |
| Mirror | Off/On | |
| Privacy Masking | Off/On (4 Area, Rectangle) | |
| Audio | ||
| Compression | N/A | |
| Network | ||
| Ethernet | RJ-45 (10/100Base-T) | |
| Protocol | HTTP;HTTPS;TCP;ARP;RTSP;RTP;RTCP;UDP;SMTP; FTP;DHCP;DNS;DDNS;PPPoE;IPV4/V6;QoS;UPnP; NTP;Bonjour;IEEE 802.1X;Multicast;ICMP;IGMP;TLS |
|
| Interoperability | ONVIF Profile S&G, API | |
| Streaming Method | Unicast/Multicast | |
| Max.User Access | 10 Users/ 20 Users | |
| Edge Storage | NAS(Network Attached Storage),Local PC for instant recording | |
| Web Viewer | IE, Chrome, Firefox, Safari | |
| Management Software | Smart PSS, DSS, DMSS | |
| Smart Phone | IOS, Android | |
| Certifications | ||
| Certifications | CE (EN 60950:2000) UL:UL60950-1 FCC: FCC Part 15 Subpart B |
|
| Interface | ||
| Video Interface | N/A | |
| Audio Interface | N/A | |
| RS485 | N/A | |
| Alarm | N/A | |
| Electrical | ||
| Power Supply | DC12V PoE(802.3af)(Class 0) | |
| Power Consumption | < 6W | |
| Environmental | ||
| Operating Conditions | -30° C ~ 60° C (-22° F ~ 140° F) / Less than 95% RH | |
| Storage Conditions | -30° C ~ 60° C (-22° F ~ 140° F) / Less than 95% RH | |
| Ingress Protection | IP67 | |
| Vandal Resistance | N/A | |
| Construction | ||
| Casing | Metal Plastic | |
| Dimensions | Φ70mm×164.7mm(2.76”x6.49”) | |
| Net Weight | 0.38Kg(0.84lb) | |
| Gross Weight | 0.44Kg(0.97lb) | |
