Description
| Camera | |||
|---|---|---|---|
| Image Sensor | 1/3″ 1.3 Megapixel progresive CMOS | ||
| Effective Pixels(Panorama) | 1280(H) x 960(V) | ||
| RAM/ROM | 256MB/16MB | ||
| Scanning System | Progressive | ||
| Minimum Illumination | 0.45Lux/F2.0(Color), 0Lux/F2.0(IR on) | ||
| S/N Ratio | More than 50dB | ||
| IR Distance | Distance up to 10m(33ft) | ||
| IR On/Off Control | Auto/ Manual | ||
| IR LEDs | 2 | ||
| Lens | |||
| Lens Type | Fixed | ||
| Mount Type | Board-in | ||
| Focal Length | 3.6mm | ||
| Max Aperture | F2.0 | ||
| Angle of View | H: 72.2°;V:52.9° | ||
| Focus Control | Fixed | ||
| Close Focus Distance | N/A | ||
| PTZ | |||
| Pan/Tilt/Rotation | Pan: 0° ~ 355° Tilt: 0° ~ 90° Rotation: 0° ~ 355° |
||
| Video | |||
| Compression | H.26/ H.264B/ H.264H. MJPEG | ||
| Streaming Capability | 2 Streams | ||
| Resolution | 1.3M(1280×960)/720P(1280×720)/ VGA(640 ×480)/QVGA(320×240) |
||
| Frame Rate | 1.3M(1~25/30fps) VGA/QVGA(1~25/30fps) |
||
| Bit Rate Control | CBR/VBR | ||
| Bit Rate | H264: 32K~10240Kbps | ||
| Day/Night | Auto(ICR)/Color/B/W | ||
| BLC Mode | BLC/HLC/DWDR | ||
| White Balance | Auto/Natural/Street Lamp/Outdoor/Manual | ||
| Gain Control | Auto/Manual | ||
| Noise Reduction | 3D DNR | ||
| Motion Detection | Off/On (4 Zone, Rectangle) | ||
| Region of Interest | Off/On (4 Zone) | ||
| Electronic Image | Support | ||
| Smart IR | Support | ||
| Digital Zoom | 16x | ||
| Flip | 0°/90°/180°/270° | ||
| Mirror | Off/On | ||
| Privacy Masking | Off/On (4 Area, Rectangle) | ||
| Audio | |||
| Compression | G.711;G.711Mu;AAC | ||
| Network | |||
| Ethernet | RJ-45 (10/100Base-T | ||
| Wi=Fi | Wi-Fi(iEEE802.11b/g/n), 50m(open field) | ||
| Protocol | HTTP;HTTPs;TCP;ARP;RTSP;RTP;UDP;SMTP;FTP; DHCP;DNS;DDNS;PPPOE;IPv4/v6;QoS;UPnP;NTP; Bonjour;802.1x;Multicast;ICMP;IGMP; |
||
| Interoperability | ONVIF, PSIA, CGI | ||
| Streaming Method | Unicast/ Multicast | ||
| Max.User Access | 10 Users/20 Users | ||
| Edge Storage | NAS(Network Attached Storage) Local PC for instant recording, Mirco SD card 128GB |
||
| Web Viewer | IE, Chrome, Firefox, Safari | ||
| Management Software | Smart PSS, DSS, Easy4ip | ||
| Smart Phone | iPhone, iPad, Android Phone | ||
| Certifications | |||
| Certifications | CE: (EN 60950:2000) UL: UL60950-1 FCC: FCC Part 15 Subpart B |
||
| Interface | |||
| Video Interface | N/A | ||
| Audio Interface | Built-in Mic & Speaker | ||
| RS485 | N/A | ||
| Alarm | N/A | ||
| Electrical | |||
| Power Supply | DC5V 2A | ||
| Power Consumption | <8.2W | ||
