Description
| SPECIFICATIONS | |
| CAMERA | |
| Image Sensor | 1/4 Sony CCD |
| Effective Pixel | PAL: 752(H)×582(V), NTSC: 768(H)×494(V) |
| Horizontal Resolution | Color: 540 TVL, B/W: 600 TVL |
| Min. Illumination | Color: 0.1Lux@( F1.6, AGC ON), 0 lux with IR B/W: 0.01Lux@( F1.6, AGC ON), 0 lux with IR |
| White Balance | Auto / Manual / ATW / Indoor / Outdoor |
| AGC | Auto / Manual |
| S/N Ratio | ≥ 50dB |
| Digital Noise Reduction | 3D DNR |
| Wide Dynamic Range | Digital WDR |
| Shutter Speed | PAL: 1 ~1/10,000s, NTSC: 1 ~1/10,000s |
| Day & Night | IR Cut Filter |
| Digital Zoom | 16X |
| Privacy Mask | 8 privacy masks programmable, optional multiple colors and mosaics |
| Focus Model | Auto / Semiautomatic / Manual |
| LENS | |
| Focal Length | 3.84 ~88.32mm, 23X |
| Zoom Speed | Approx 3.0s(Optical Wide-Tele) |
| Angle of View | 50.2 ~2.44degree(Wide-Tele) |
| Min. Working Distance | 10 ~1000mm (Wide-Tele) |
| Aperture Range | F1.6 ~ F4.5 |
| PAN AND TILT | |
| Pan / Tilt Range | Pan: 360°endless; Tilt: -15° ~90° (Auto Flip ) |
| Pan / Tilt Range | Pan Manual Speed: 0.1° ~160°/s, Pan Preset Speed: 240°/s Tilt Manual Speed: 0.1° ~120°/s, Tilt Preset Speed: 200°/s |
| Proportional Zoom | Rotation speed can be adjusted automatically according to zoom multiples |
| Number of Preset | 256 |
| Patrol | 8 patrols, up to 32 presets per patrol |
| Pattern | 4 patterns, with the total recording time not less than 10 minutes |
| Power-off Memory | Support |
| Park Action | Preset / Patrol / Pattern / Pan / Tilt / Auto / Random / Frame / Panorama scan |
| PTZ Position Display | Support |
| Compass | Support , the north can be set |
| Scheduled Task | Preset / Patrol / Pattern / Pan / Tilt / Auto / Random / Frame / Panorama scan |
| INFRARED | |
| IR Range | Up to 100m |
| IR irradiation angle | Automatically adjusted, depending on the zoom ratio |
| INPUT/OUTPUT | |
| Video Output | 1.0V[p-p] / 75Ω, PAL / NTSC composite, BNC |
| GENERAL | |
| RS-485 Protocols | HIKVISION, Pelco-P, Pelco-D, self-adaptive |
| Power | 24 VAC, max.30W |
| Working Temperature | -30°C ~65°C (-22°F ~149°F) |
| Humidity | 90% or less |
| Protection Level | IP66 TVS 4,000V lightning protection, surge protection and voltage transient protection |
| Dimensions | Φ245 × 399mm (Φ9.65 × 15.71in) |
| Weight | Approx. 5.5kg(12.13Ibs) |
| Mount Option | Corner mount: DS-1601ZJ-corner; Power box mount:DS-1634ZJ |
