Description
| Specifications | |
| CAMERA | |
| Image Sensor | 1/3-inches Progressive Scan CMOS |
| Min. illumination | Color: 0.028 @ f/2.0, AGC on; BW: 0lux with IR |
| Shutter speed | 1/3 s to 1/10,000s |
| Slow shutter | Support |
| Lens | 4mm, 6mm options Angle of view: 83°(4mm), 56°(6mm) |
| Lens mount | M12 |
| Day & night | IR cut filter with auto switch |
| Digital noise reduction | 3D DVR |
| Pan/Tilt/Rotation | 3-axis positioning |
| Wide dynamic range | 120dB |
| COMPRESSION STANDARD | |
| Video compression | H.264 /H.264 / MJPEG |
| H.264 Type | Main Profile |
| Video Bit rate | 256Kbps – 16Mbps |
| Dual Stream | Yes |
| IMAGE | |
| Max. Image Resolution | 2688 x 1520 |
| Frame rate | 20fps(2688×1520), 30fps(1920×1080, 1280×720) |
| Image settings | Compression, color, saturation, brigtness, contrast, sharpness, rotate mode, privacy mask |
| Backlight Compensation | Yes, zone optional |
| ROI | Support |
| ANALYTICS | |
| Smart Features | Line crossing detection, intrusion detection |
| NETWORK | |
| Network storage | NAS (Support NFS,SMB/CIFS) |
| Alarm triggers | Motion detection, line crossing detection, intrusion detection, tamper alarm, network disconnect, IP address conflict, storage exception |
| Protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour |
| Security | Flash-precention, dual stream, heartbeat, mirror password protection, privacy mask, watermark, IP address filtering, anonymous access |
| Standards | ONVIF, PSIA, CGI, ISAPI |
| INTERFACE | |
| Communication interface | 1 RJ45 10M / 100M ethernet port |
| GENERAL | |
| Operating conditions | -30 °C ~ 60 °C (-22°F ~ 140 °F) humidity 95% or less (non-condensing) |
| Power supply | 12 VDC ± 10% , PoE (802.3af)± 10% |
| Power consumption | Max. 7.5W |
| IR range | 50 meters |
| Ingress protection level | IP67 |
| Dimensions (mm) | 299.71 x 86.48 x 85.11 |
| Weight | 1200g |
[rt_button_style title=”download catalog” link=”url:https://www.aacgroup.com.my/uploads/product_pdf/DS-2CD2T42WD-I5.pdf|||”]
