Description
[rt_button_style title=”CATALOG” link=”url:https://www.saxco.com.my/wp-content/uploads/2018/02/DH-HAC-HFW-1200RP-VF-S3-DIP.pdf|||”]
| Camera | ||
|---|---|---|
| Image Sensor | 1/2.7″ 2 Megapixel CMOS | |
| Effective Pixels | 1930(H)x1088(V) | |
| Electronic Shutter | 1/50s~1/100,000s | |
| Video Frame Rate | 25fps@1080P | |
| Synchronization | Internal | |
| Mini.illumination | 0.01Lux@F1.2(AGC ON), 0Lux IR on | |
| Video Output | 1-channel BNC HDCVI high definition video output | |
| Camera Features | ||
| Max.IR LEDs Length | 30m,Smart IR | |
| Backlight Compensation | N/A | |
| Day/Night | Auto(ICR)/Color/B/W | |
| Noise Reduction | 2D | |
| OSD Menu | N/A | |
| Lens | ||
| Focal Length | 2.7~12mm | |
| Angle of View | H: 109º~35º | |
| Mount Type | 14 | |
| General | ||
| Power Supply | DC12V±20% | |
| Power Consumption | Max 2.8W | |
| Working Environment | -30°C~ 60°C / Less than 95%RH (no condensation) | |
| Transmission Distance | Over 500m via 75-3 coaxial cable | |
| Ingress Protection | IP67 | |
| Dimensions(W x D x H) | 213mm x 80mm x 72mm | |
| Weight | 0.55KG | |
| Material | Metal | |
