SpecificationsDownload
System | ||
---|---|---|
Main Processor | Embedded Processor | |
Operating System | Embedded LINUX | |
Display | ||
Interface | 1 HDMI ,1 VGA,1 TV | |
Resolution | 1920×1080, 1280×1024, 1280×720, 1024×768 | |
Multi-screen Display | 1/4/8/9/16/25 | |
OSD | Camera title, Time, Video loss, Camera lock, Motion detection, Recording | |
Video Detection and Alarm | ||
Trigger Events | Recording, PTZ, Tour, Video Push, Email, FTP,Snapshot, Buzzer and Screen Tips | |
Video Detection | Motion Detection, MD Zones: 396 (22 × 18), Video Loss and Tampering | |
Alarm input | — | |
Relay Output | — | |
Playback and Backup | ||
Playback | 1/4/9/16 | |
Search Mode | Time /Date, Alarm, MD and Exact Search (accurate to second) | |
Playback Function | Play, Pause, Stop, Rewind, Fast play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Full Screen, Repeat, Shuffle, Backup Selection, Digital Zoom |
|
Backup Mode | USB Device/Network | |
Storage | ||
Internal HDD | 2 SATA Ports, up to 8TB capacity for each disk | |
eSATA | — | |
Auxiliary Interface | ||
USB | 2 USB Ports (1 USB 3.0,1 USB 2.0) | |
RS232 | — | |
RS485 | 1 Port, for PTZ Control | |
Third-party Support | ||
Third-party Support | Dahua, Arecont Vision, AXIS, Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videotec, Vivotek, and more |
|
Audio and Video | ||
HDCVI Camera Input | 32 Channel | |
IP Camera Input | 16 Channel, each channel up to 5MP | |
Audio In/Out | 1/1, RCA | |
Two-way Talk | Reuse audio in/out, RCA | |
Recording | ||
Compression | H.264 | |
Resolution | 1080N, 720P, 960H, D1, HD1, BCIF, CIF, QCIF | |
Record Rate | Main Stream: 1080N(12fps)/720P(15fps)/960H/D1/ HD1/BCIF/CIF/QCIF (1~25/30fps) Sub steram: CIF/QCIF(1~7fps) |
|
Bit Rate | 1Kbps ~ 6144Kbps Per Channel | |
Record Mode | Manual, Schedule (Regular, Continuous), MD (Video detection: Motion Detection, Video Loss,Tampering), Alarm, Stop |
|
Record Interval | 1 ~ 60 min (default: 60 min), Pre-record: 1 ~ 30 sec, Post-record: 10 ~ 300 sec | |
Network | ||
Interface | 1 RJ-45 Port (1000M) | |
Network Function | HTTP, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP,NTP, DHCP, DNS, IP Filter, PPPoE,DDNS, FTP, Alarm Server,P2P, IP Search (Support Dahua IP camera, DVR, NVS, etc.) |
|
Max. User Access | 128 users | |
Smart Phone | iPhone, iPad, Android | |
Interoperability | ONVIF 2.42, CGI Conformant | |
Electrical | ||
Power supply | DC12V/5A | |
Power consumption | <20W (Without HDD) | |
Environmental | ||
Operating Conditions | -10°C ~ 55°C ( 14°F ~ 131°F), 0~ 90% RH | |
Storage Conditions | -20°C ~ 70°C (-4°F ~ 158°F) , 0~ 90% RH | |
Construction | ||
Dimensions | 1U, 375mm×285mm×55mm (14.8″ x 11.2″ x 2.2″) | |
Net Weight | 2.35kg (5.2 lb) (without HDD) | |
Gross Weight | 3.2kg (7.05lb) | |
Installation | Desktop installation |
