Description
| Camera | ||
|---|---|---|
| Image Sensor | 1/3″4 Megapixel progressive scan CMOS | |
| Effective Pixels | 2688(H)x1520(V) | |
| Scanning System | Progressive | |
| Electronic Shutter Speed | Auto/Manual, 1/3(4)~1/100000s | |
| Min.Illumination | 0.01Lux/F2.0 Color), 0Lux/F2.0(IR on) | |
| S/N Ratio | More than 50dB | |
| Video Output | N/A | |
| Camera Features | ||
| Max.IR LEDs Length | 30m | |
| Day/Night | Auto(ICR)/Color/B/W | |
| Backlight Compensation | BLC/HLC/WDR(120dB) | |
| White Balance | Auto/Manual | |
| Gain Control | Auto/Manual | |
| Noise Reduction | 3D | |
| Privacy Masking | Up to 4 areas | |
| Lens | ||
| Focal Length | 3.6mm (2.8mm, 6mm optional) | |
| Max Aperture | F2.0 (F2.0/F2.0) | |
| Focus Control | Manual | |
| Angle of View | H: 84°/106°/56° | |
| Lens Type | Fixed lens | |
| Mount Type | Board-in Type | |
| Video | ||
| Compression | H.264/H.264B/H.264H/ MJPEG | |
| Resolution | 4M(2688× 1520)/4M(2560× 1440)/3M(2304× 1296)/1080P(1920× 10 80)/720P(1280× 720)/D1(704× 576/704× 480)/CIF(352× 288/352× 240) |
|
| Frame Rate | Main Stream: 4M(1/20fps)/3M(1~25/30fps) Sub Stream: D1/CIF(1~25/30fps) Third Stream: 720P(1-20fps) |
|
| Bit Rate | H.264: 32Kbps~10Mbps | |
| Corridor Mode | Support | |
| Audio | ||
| Compression | G.711a/ G.711u/ AAC(only for -AS) | |
| Interface | 1/1 chennel In/Out(only for -AS) | |
| Smart Function | ||
| Smart Detection | -Tripwire -Intrusion -Abandoned/Missing -Scene Change -Audio Detect -Face Detect |
|
| Network | ||
| Ethernet | RJ-45 (10/100Base-T) | |
| Wi-Fi | N/A | |
| Protocol | IPv4/IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS, Bonjour, 802.1x |
|
| Compatibility | ONVIF PSIA CGI | |
| Max.User Access | 20 users | |
| Smart Phone | iPhone, iPad, Android, Windows Phone | |
| Auxiliary Interface | ||
| Memory Slot | Micro SD Max 128GB (only for -AS) | |
| RS485 | N/A | |
| Alarm | 1/1 Chennel In/Out (only for -AS) | |
| PIR Sensor Range | N/A | |
| General | ||
| Power Supply | DC12V, PoE (802.3af) | |
| Power Consumption | Max 4W | |
| Working Environment | -30°C~ 60°C, Less than 95% RH | |
| Ingress Protection | IP67 | |
| Vandal Resistance | IK10 | |
| Dimensions | Φ110mm× 81mm | |
| Weight | 0.33KG (0.47kg with package) | |
[rt_button_style title=”CATALOG” link=”url:https://www.saxco.com.my/wp-content/uploads/2018/02/DH-IPC-HDBW4421E.pdf|||”]
