Description
| Camera | ||
|---|---|---|
| Image Sensor | 1/3″ 4 Megapixel progressive scan CMOS | |
| Effective Pixels | 2688(H)x1520(V) | |
| Scanning System | Progressive | |
| Electronic Shutter Speed | Auto/Manual, 1/3(4)s~1/100000s | |
| Min.Illumination | 0.1Lux/F2.0(Color), 0Lux/F2.0(IR on) | |
| S/N Ratio | More than 50dB | |
| Video Output | N/A | |
| Camera Features | ||
| Max.IR LEDs Length | 30m | |
| Day/Night | Auto(ICR)/Color/B/W | |
| Backlight Compensation | BLC/HLC/DWDR | |
| White Balance | Auto/Manual | |
| Gain Control | Auto/Manual | |
| Noise Reduction | 3D | |
| Privacy Masking | Up to 4 areas | |
| Lens | ||
| Focal Length | 2.8mm(3.6mm optional) | |
| Max Aperture | F2.0(F2.0) | |
| Focus Control | Manual | |
| Angle of View | H: 106°(84°) | |
| Lens Type | Fixed lens | |
| Mount Type | Board-in Type | |
| Video | ||
| Compression | H.264/H.264H/H.264B/MJPEG | |
| Resolution | 4M(2688×1520)/3M(2304×1296)/1080P(1920×1080)/720P(1280× 720)/ D1(704×576/704×480) /CIF(352×288/352×240) |
|
| Frame Rate | Main Stream: 4M(1 ~ 20fps)/3M(1 ~ 25/30fps) Sub Stream: D1(1 ~ 25/30fps) |
|
| Bit Rate | H.264: 32kbps～8192kbps | |
| Corridor Mode | Support | |
| Audio | ||
| Compression | N/A | |
| Interface | N/A | |
| Network | ||
| Ethernet | RJ-45 (10/100Base-T) | |
| Wi-Fi | N/A | |
| Protocol | IPv4/IPv6, HTTP, HTTPS, TCP/IP, UDP, UPnP, ICMP, IGMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS |
|
| Compatibility | ONVIF, CGI | |
| Max.User Access | 20 useres | |
| Smart Phone | iPhone, iPad, Android, Window Phone | |
| Auxiliary Interface | ||
| Memory Slot | N/A | |
| RS485 | N/A | |
| Alarm | N/A | |
| PIR Sensor Range | N/A | |
| General | ||
| Power Supply | DC12V, PoE (802.3af) | |
| Power Consumption | <4.3W(IR on) | |
| Working Environment | -30°C~ 60°C, Less than 95% RH | |
| Ingress Protection | IP67 | |
| Vandal Resistance | N/A | |
| Dimensions | Φ108mm×84mm | |
| Weight | 0.25Kg(with package 0.38Kg) | |
