| SPECIFICATIONS | |
| CAMERA | |
| Image Sensor | 1/3 DIS |
| Signal System | PAL/NTSC |
| Effective Pixels | 976 (H) × 496 (V) |
| Min. Illumination | 0.1 Lux @ (F1.2,AGC ON), 0 Lux with IR |
| Shutter speed | PAL: 1/50s to 1/100,000s, NTSC: 1/60s to 1/100,000s |
| Lens | 3.6 mm, Angle of view: 68.4° |
| Lens Mount | M12 |
| Angle Adjustment | Pan: 0 – 360°; Tilt: 0 – 75°; Rotation: 0 – 360° |
| Day & Night | IR cut fi lter with auto switch |
| Horizontal Resolution | 700 TVL |
| Synchronization | Internal synchronization |
| Video Output | 1Vp-p composite output (75 Ω/BNC) |
| S/N Ratio | More than 62 dB |
| BLC | On |
| GENERAL | |
| Working Temperature/Humidity | -40 °C – 60 °C (-40 °F – 140 °F) Humidity 90% or less (non-condensing) |
| Power Supply | 12V DC |
| Power Consumption | Max. 1.8W |
| IR Range | 20 meters |
| Dimensions | Φ89.5 × 69.8mm(Φ3.52in × 2.75in) |
| Weight | 200g (0.44lbs) |
