Description
| SPECIFICATIONS | |
| CAMERA | |
| Image Sensor | 1/3 DIS |
| Signal System | PAL/NTSC |
| Effective Pixels | 976 (H) × 496 (V) |
| Min. Illumination | 0.1 Lux @ (F1.2, AGC ON) 0.14 Lux @ (F1.4, AGC ON) |
| Shutter speed | PAL: 1/25s to 1/100,000s, NTSC: 1/30s to 1/100,000s |
| Lens | 2.8 – 12 mm @ F1.4, Angle of view: 80° – 27.2° |
| Lens Mount | φ14 |
| Angle Adjustment | Pan: 0 – 355°, Tilt: 0 – 180°, Rotation: 0 – 355° |
| Day & Night | IR cut fi lter with auto switch |
| Horizontal Resolution | 700 TVL |
| Synchronization | Internal synchronization |
| Video Output | 1Vp-p composite output (75 Ω/BNC) |
| S/N Ratio | More than 62 dB |
| BLC | On |
| GENERAL | |
| Working Temperature/Humidity | -40 °C – 60 °C (-40 °F – 140 °F) Humidity 90% or less (non-condensing) |
| Power Supply | 12V DC |
| Power Consumption | Max. 4.2W |
| IR Range | 30 meters |
| Dimensions | Φ 136 × 101 mm (Φ 5.35in × 3. 98in) |
| Weight | 380g (0.84lb) |
[rt_button_style title=”Download Catalog” link=”url:https://www.aacgroup.com.my/uploads/product_pdf/DS-2CE55A2P-VFIR.pdf|||”]
