Description
| SPECIFICATIONS | |
| CAMERA | |
| Image Sensor | 1/3 DIS |
| Signal System | PAL/NTSC |
| Effective Pixels | 976 (H) × 496 (V) |
| Min. Illumination | 0.1 Lux @ (F1.2,AGC ON), 0 Lux with IR |
| Shutter speed | PAL: 1/50s to 1/100,000s, NTSC: 1/60s to 1/100,000s |
| Lens | 3.6mm, Angle of view: 68.4° (3.6 mm) |
| Lens Mount | M12 |
| Angle Adjustment | Pan: 0 – 360°, Tilt: 0 – 75°, Rotation: 0 – 360° |
| Day & Night | IR cut fi lter with auto switch |
| Horizontal Resolution | 700 TVL |
| Synchronization | Internal synchronization |
| Video Output | 1Vp-p composite output (75 Ω/BNC) |
| S/N Ratio | More than 62 dB |
| BLC | On |
| GENERAL | |
| Working Temperature/Humidity | -40 °C – 60 °C (-40 °F – 140 °F) Humidity 90% or less (non-condensing) |
| Power Supply | 12 V DC |
| Power Consumption | Max. 5 W |
| Ingress Protection | IP66 |
| IR Range | 40 meters |
| Dimensions | Φ114.6× 89.1mm(Φ4.5in × 3.5in) |
| Weight | 300 g (0.66 lbs) |
