SPECIFICATIONS | |
VIDEO / AUDIO INPUT | |
Video compression | H.264 |
Analog and HD-TVI video input | 8CH, BNC interface (1.0Vp-p, 75 Ω) |
Supported camera types | 720P/25, 720P/30 |
Supported AHD input | 720P/25, 720P/30, CVBS |
IP video input | 2-ch, up to 960p resolution |
Audio input / Two-way audio input | 1-ch, RCA (2.0 Vp-p, 1 KΩ) |
VIDEO / AUDIO OUTPUT | |
HDMI / VGA output | 1920 × 1080 / 60 Hz,1280 × 1024 / 60 Hz, 1280 × 720 / 60 Hz, 1024 × 768 / 60 Hz |
Audio Input | 1-ch, RCA(Linear, 1ohm) |
NETWORK MANAGEMENT | |
Remote connections | 128 |
Network protocols | TCP/IP, PPPoE, DHCP, DNS, DDNS, NTP, SADP, SMTP, SNMP, NFS, iSCSI, UPnP™, HTTPS |
ENCODING | |
Video compression standard | H.264 |
Encoding resolution | 720P/WD1/4CIF/VGA/CIF |
Frame rate | 1/16fps, real time frame rate |
Video bitrate | 32kps to 4Mbps |
Stream type | Video/Audio |
Dual-stream | Support |
Audio compression stanrad | G.711u |
Audio bitrate | 64kbps |
Synchronous playback | 8-ch |
HARD DISK | |
SATA | 1 SATA interface |
Capacity | Up to 6 TB capacity for each disk |
EXTERNAL INTERFACE | |
Network interface | 1x 10M / 100M self-adaptive Ethernet interface |
USB port | 2× USB2.0 |
GENERAL | |
Power supply | 12V DC |
Consumption (without hard disks) | ≤ 12W |
Working temperature | -10 ºC ~ 55 ºC (14 ºF ~ 131 ºF) |
Working humidity | 10% ~ 90% |
Chassis | 260mm chassis |
Dimensions (W × D × H) | 260 × 222 × 45mm |
Weight (without hard disks) | ≤ 1Kg (2.2lb) |
