SPECIFICATIONS | |
VIDEO / AUDIO INPUT | |
Video compression | H.264 |
Analog and HD-TVI video input | 16CH, BNC interface (1.0Vp-p, 75 Ω) |
Supported camera types | 1080P/25, 1080P/30, 720P/25, 720P/30, 720P/50, 720P/60 |
Supported AHD input | 720P/25, 720P/30 |
IP video input | 2-ch, up to 1080p resolution |
Audio input / Two-way audio input | 1-ch, RCA (2.0 Vp-p, 1 KΩ) |
VIDEO / AUDIO OUTPUT | |
CVBS output | Support |
HDMI / VGA output | 1-ch, 4K(3840×2160), 2K(2560×1440), 1920×1080, 1280×1024, 1280×720, 1024×768 |
Ecoding resolution | When 1080P lite mode not enabled 1080P(non-real-time) / 720P / VGA / WD1 / 4CIF / CIF When 1080P lite mode enabled; 1080P lite / 720P lite / 720P / VGA / WD1 / 4CIF / CIF |
Frame rate | Main stream: 1/16fps to Real-time frame rate Sub stream: WD1 / 4CIF@12fps, CIF/QVGA/QCIF@ real-time |
Video bitrate | 32kbps to 6Mbps |
Audio output | 1-ch, RCA(Linear, 1ohm) |
Audio bitrate | 64kbps |
Dual stream | Support |
Stream type | Video / Audio |
Synchronous playback | 16-ch |
NETWORK MANAGEMENT | |
Remote connections | 128 |
Network protocols | TCP/IP, PPPoE, DHCP, DNS, DDNS, NTP, SADP, SMTP, SNMP, NFS, iSCSI, UPnP™, HTTPS |
HARD DISK | |
SATA | 2 SATA interface |
Capacity | Up to 6 TB capacity for each disk |
EXTERNAL INTERFACE | |
Network interface | 1x 10M / 100M self-adaptive Ethernet interface |
Serial interface | 1 standard RS-485 serial interface, half duplex |
USB port | 2× USB2.0 |
GENERAL | |
Power supply | 12V DC |
Consumption (without hard disks) | ≤ 20W |
Working temperature | -10 ºC ~ 55 ºC (14 ºF ~ 131 ºF) |
Working humidity | 10% ~ 90% |
Dimensions (W × D × H) | 380 x 320 x 48mm |
Weight (without hard disks) | ≤ 2Kg (4.4lb) |
