Description
| Specifications | |
| VIDEO / AUDIO INPUT | |
| IP video input | 8CH |
| Two-way audio input | 1-ch, RCA (2.0 Vp-p, 1kΩ) |
| NETWORK | |
| Incoming bandwidth | 50Mbps |
| Outgoing bandwidth | 80Mbps |
| Remote connection | 128 |
| VIDEO / AUDIO OUTPUT | |
| Decoding resolution | 5MP / 3MP / 1080p / UXGA / 720p / VGA / 4CIF / DCIF / 2CIF / CIF / QCIF |
| Frame rate | Main stream: 50 fps (P) / 60 fps (N) Sub-stream: 50 fps (P) / 60 fps (N) |
| HDMI/VGA output | 1-ch, resolution: 1920 × 1080P /60Hz, 1600 × 1200 /60Hz, 1280 × 1024 /60Hz, 1280 × 720 /60Hz, 1024 × 768 /60Hz |
| Audio output | 1-ch, RCA (Linear, 1kΩ) |
| DECODING | |
| Live / Playback resolution | 5MP / 3MP / 1080P / UXGA / 720P / VGA / 4CIF / DCIF / 2CIF / CIF / QCIF |
| Synchronous playback | 8-ch@720P, 6-ch@1080P |
| HARD DISK | |
| SATA | 2 SATA interfaces for 2 HDDs |
| Capacity | Up to 4TB for each disk |
| EXTERNAL INTERFACE | |
| Network interface | 1 RJ-45 10 /100 /1000 Mbps self-adaptive Ethernet interfaces (1 for /P model) |
| USB interface | 1 × USB 2.0 1 × USB 3.0 |
| Alarm in/out | 4 / 1 |
| PoE | |
| Interface | 8 independent 100 Mbps PoE network interfaces |
| Max. Power | 120W |
| Supported standard | AF and AT |
| OTHERS | |
| Power supply | 220V AC |
| Consumption | ≤ 10W |
| Working temperature | -10 ºC ~ 55 ºC ( 14 ºF~ 131 ºF) |
| Working humidity | 10 % ~ 90 % |
| Chassis | 19-inch rack-mounted 1U chassis |
| Dimensions | 445 × 290 × 45mm (17.5 ×11.4 × 1.8 inch) |
| Weight | ≤ 1 Kg (2.2 lb) |
[rt_button_style]
[rt_button_style title=”download catalog” link=”url:https://www.aacgroup.com.my/uploads/product_pdf/DS-7608NI-E2:8P.pdf|||”]
