Access Pro-L Barrier

Access Pro L Barrier

Compare
Category:
Description

Description

Technical data Access Pro-L
Barrier width Max. 6,0 m
Opening/closing time 4,0 s
Power consumption Max. 25 W
Drive technology MHTM™
Voltage 85-264 VAC, 50/60 Hz
Duty cycle 100%
Housing dimensions (L x W x H) 315 x 360 x 915 mm
Enclosure rating IP 54
Temperature range -30 to 55 °C
Weight 40 kg
Features Access Pro-L
Standard colours RAL 2000, 9006, 9007
VarioBoom barrier arm Standard
Control system MGC Pro
Integrated 2-channel detector for induction loops Standard
Modular expansion of control system Freely expandable
Variable I/O assignment Standard
No. of digital inputs 8
No. of relays/digital outputs 6/4
Input for safety light barrier with test Standard
Selectable closing speed Standard
Selectable opening speed Standard
Options Access Pro-L
Special colours x
Boom extension set x
Pendulum support x
Support post x
Boom drop contact x
Boom locking set x
Boom illumination, red x
Light strips, red/green x
Cover illumination x
Key-operated switch x
Radio module x
Ethernet module x
RS485 module x
CAN module x
Second detector module x
GSM module x
Safety light barrier x
Battery backup x
